Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)

Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 260

An illustration from Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc, 1919, leaf 260 — easuse a rather wide spacing; for small areas use a narrow spacing.In showing a section of any machine, the different parts are dis-tinguished by altering the slope of the section lines, whether of thesame material or not. Draw the sixteen figures in full and then draw the border linesof the plate.…
