Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)

Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 268

An illustration from Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc, 1919, leaf 268 — < >. Fig. G8. Octahedron Fig. 69. Prism Fig. 70. Right Prism lateral faces, which are parallelograms, Fig. 69. The altitude of aprism is the perpendicular distance between the bases. The areaof the lateral faces is called the lateral area. 113 MECHANICAL DRAWING Prisms are called triangular,…

Mechanical drawing · Blueprinting

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
