Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 397
Fig. 1212.—Application of Slip for Setting Out Shoulders for Ovolo Edge of Posts and Muntins. touched, except for jacking over where themortice gauge is run down. Frame and Linings.—Many of the pro-cesses involved in setting out and making theframe have already been explained in con-nection with… … Fig. 1214.—Shoulders Set Out on MouldedEdge. the depth the ovolo works down ; then gaugeJ in. for the last 3 in., equal to the depth therebate is worked down for the doors ; theseshould be accurately cut away down to thegauge lines, then the slip will have theappearance shown in Fig. 1216. Lay…
Carpentry · Joinery
