Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)

Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 311

An illustration from Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc, 1919, leaf 311 — FL. 123. Projections of a Triangular Prism or Block \ \ ^\ \ … 134. Projections of a Triangular Block with Square Hole ROTATING AND INCLINING OF OBJECTSMethod of Rotating Object. The natural way to place ant to be ahowD by projections would be in the simplest position;that is, with an edge or face parallel to either the horizontal or 156 MECHANICAL DRAWING 91…

Mechanical drawing · Blueprinting

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
