Collins, A. Frederick (Archie Frederick), 1869- · Boston, Small, Maynard and company · leaf 174
1 SIDE LOWERCROSS/7# iA Fig. 59. The Engine Truck Frame (End View) ders and steam chests are bolted to the sides ofthe truck frame as shown in the cross-section endview Fig. 59; consequently small changes must A Model Atlantic Type Locomotive 159 be made in the design and construction of theengine… … CROSSHEADBLOCK Fig. 60. The Cross-head Guide and Block inch wide, % inch high and 1% inch long, andmake the piston rods and slide valves to fit asshown at A in Fig. 60; the chief sizes we markedon the drawings. The crosshead guide is also shown at A inFig. 60, as well as the way it is screwed to…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
