The boys' book of engine-building; (1918)

Collins, A. Frederick (Archie Frederick), 1869- · Boston, Small, Maynard and company · leaf 52

An illustration from The boys' book of engine-building;, 1918, leaf 52
easures% inch wide and % inch long. File the endsmooth and have a machinist or a steam-fitterthread one end of it and screw a standard sized 1 A thin, round tool for enlarging and tapering holes. Two Simple Steam Turbine Engines 37 union, that is a pipe coupling, on to it so that itcan be joined to… … ^45?

Steam-engines
