is simple and easilyunderstood. The windows are 3 feet wide in theopening and 5 ft. 3 in. from lintel to sill; so, ARCHITECTURAL DRAWING SELF TAUGHT 115 keeping these figures in mind, the window andsashes may be laid out readily. The door, fromfloor to lintel, including fanlight, is 8 feet high,by… … ^/z^— >!^;m;!{iv H Fig. 107. foundation footing is shown at O; the projectionof door-steps is also shown on the ground line. All these examples should first be made inpencil, after which, when corrected, they may befilled in with ink. I have mentioned something regarding foot-ings for…
