Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 508
. The elevation shown at Fig. 103 requires butlittle explanation, as it is simple and easilyunderstood. The windows are 3 feet wide in theopening and 5 ft. 3 in. from lintel to sill; so, ARCHITECTURAL DRAWING SELF TAUGHT 115 keeping these figures in mind, the window andsashes may be laid out… … Fig. 107. foundation footing is shown at O; the projectionof door-steps is also shown on the ground line. All these examples should first be made inpencil, after which, when corrected, they may befilled in with ink. I have mentioned something regarding foot-ings for foundations and it may not be…
Architecture · Architectural drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
