ARCHITECTURAL DRAWING SELF TAUGHT 137 … Fig. 135. point; and secondly, to have the effect of pro-ducing an equal number of bricks in the archexcluding the key, so that it maybe finished the same on each side.The next arch Is drawn uponthe same principles as the ogeecurve shown in Fig. 135, andwuththe construction lines given re-quires no…
