Builder's architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1903)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919 · Chicago : F.J. Drake & Co. · leaf 196
Fig. 159. 158 ARCHITECTURAL DRAWING SELF TAUGHT shown in section. This style of finish is calledblock finish, because of the turned block being placed on the corner.Fig. i6i exhibits acorner of a balloonframe, showing themanner of placingthe studs, cornerboards and otherfinish. I show at Fig. 162a…
Architectural drawing
