Builder's architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1903)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919 · Chicago : F.J. Drake & Co. · leaf 204
Fig. 165. ARCHITECTURAL DRAWING SELF TAUGHT 16S Each item, too, has a constructive value, asall are drawn from examples of actual work,and will, therefore, convey in some measure atrue knowledge of construction, without whichthe work of the mechanical draftsman has butlittle value. Straight Line.… … Fig. 166. SOME ORNAMENTAL EXAMPLES We have now reached a stage where anattempt at ornamental geometrical drawing ispermissible, and though it is not my intentionto go deeply into this subject, a few examplesalong with brief descriptions will probably startsome of my readers on a course of…
Architectural drawing
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
