Builder's architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1903)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919 · Chicago : F.J. Drake & Co. · leaf 231
have been a favorite ornament with the olddesigners. … Fig, 209. The ornament or rosette shown in Fig. 209^^ isa Roman one used largely during the period of 188 ARCHITECTURAL DRAWING SELF TAUGHT the decay of art,about the secondcentury of our era.It is quite elabo-rate, but is not byany means effec-tive. The orna-ment shown in Fig.2IO is also Romanbut…
Architectural drawing
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
