Builder's architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1903)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919 · Chicago : F.J. Drake & Co. · leaf 290
s order. The capital admits of great diversity ofcharacter- and decoration—it sometimes is with-out necking, sometimes with; which may eitherbe plain or decorated, to suit the entire design.The capital may also be modified in its pro-portions, first as regards its general proportionto the column;… … Fig. 241. ARCHITECTtJRAL DRAWING SELF TAUGHT 2S5 also of the volutes may be either single ormanlold, and the eye or center of the spiralmay be made larger or smaller, flat or convex,or curved as a rosette. Fig. 242 represents an example of the Corin-thian order, from the Arch of Hadrian, atAthens.…
Architectural drawing
