An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 878

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 878
half its diameter. He jilaces a soit of triglyjih in the frieze, whicharises from a niisconception of the text of \itruvius. The height of his pedestal is a fourthpart of that of the column, with base and capital, less half a diameter. The whole heightin our nieasiae is 21 modules and 9 parts.… … capital ; and C, a plan of the base. In the frieze the channelled projections arc calledtrii/li/phs, and the spaces between them mctojju:, which should ui breadth be equal to ihcif fcS PRACTICE OF ARCHITECIUKE. Boos ill. heigfat. vhirli k tbat of the frieie. The shaft is osuallj channelled widi…
