Builder's architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1903)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919 · Chicago : F.J. Drake & Co. · leaf 33
Fig. 2. Fig. I, or dovetailed into the board across thegrain as shown av Aig. 2. At Fig. 3 a much … ARCHITECTURAL DRAWING SELF TAUGHT 19 better board is shown and one I can recommendas possessing nearly all the qualities of a perfectboard. A glance at the illus-tration will explain thegood qualities of thisstyle of board. The woodused should be carefully ^Fig. 3. selected pine or basswood with…
Architectural drawing
