Builders' architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1917)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919, Frederick J. Drake & Co · Chicago, F. J. Drake · leaf 189
Fig- 174- each other, the distances being shown at i h g. Another illustration of a square being set diagonally is shown at Fig. 174, which illustrates ARCHITECTURAL DRAWING SELF TAUGHT 167 an open balustrade in Gothic style. The studentshould have no difficutly whatever in laying thisdiagram off,…
Architectural drawing · Architecture, Domestic
