Builders' architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1917)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919, Frederick J. Drake & Co · Chicago, F. J. Drake · leaf 24
Fig. 2. Fig. I, or dovetailed into the board across thegrain as shown a^ rig. 2. At Fig. 3 a much … ARCHITECTURAL DRAWING SELF TAUGHT 19 better board is shown and one I can recommendas possessing nearly all the qualities of a perfectboard. A glance at the illus-tration will explain thegood qualities of thisstyle of board. The woodused should be carefully ^Fig. 3. selected pine or basswood with…
Architectural drawing · Architecture, Domestic
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
