The builder's practical director; or, Buildings for all classes, containing plans, sections and elevations for the erection of cottages, villas, farm buildings, dispensaries, public schools, &c., with detailed estimates, quantities, prices, &c. .. (1855)

Leipzig, Dresden : A. H. Payne; [etc., etc.] · leaf 169

An illustration from The builder's practical director; or, Buildings for all classes, containing plans, sections and elevations for the erection of cottages, villas, farm buildings, dispensaries, public schools, &c., with detailed estimates, quantities, prices, &c. .., 1855, leaf 169
No. 12. Exhibits the Grecian ogee, with ovolo finished witli the common ogee; this willalso form an architrave or base. 80 STEENGTH OP MATERIALS. … No. 13. Exhibits an architrave formed bythe cock bead, and ogee and bead. STRENGTH OF MATERIALS. The following tables of the transverse sti-ength of various materials or their resistance topressiuc were determined by experiments on the various materials by Mr. Barlow.Elastic strength of lbs. Good…

Architecture
