Fig. 403 Gem Holt. … Fig. 404.—Chain tised bolts are preferred. The neatest mortise bolt is probably theknob bolt shown in Fig. 375, or an extra bolt in the lock, as in thethree-bolt chamber door lock. FINISHED HARDWARE—BOLTS. 381 When the door is already fitted with a common knob lock, a cylin-der mortise bolt, of…
