Building construction and superintendence, by F.E. Kidder ... (1896)
Kidder, Frank E. (Frank Eugene), 1859-1905 · New York, W.T. Comstock · leaf 435
Fig. 465 The side flanges, F, F, extend the full length of the cap, and thebracket bearing at N is riveted to the side flange and to the bottomring. The post caps for girder in one direction only are made with-out the bearing N, as shown in Fig. 472. HEAVY FRAMING. 43 * The upper post may be capped…
