Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 441
etail sawhalfway through at the lower end, and asimilar one at the top end, but undercut asshown at a in Fig. 1331, and in Fig. 1332.Turn over the stile and bore a f-in. hole ateach end exactly where the rebate fines crossthe parting groove. Stop the hole when itreaches the groove, and run the saw… … Fig. 1332. -Front and Edge Views of Pocket Fig. 1333.—End of Pulley Stile Wedged and NailedPiece in Sill. 1315 and 1316). The back fining is ploughed but do not knock the piece out. Form into the inside lining and nailed on the edge rebates as on the head, and fit in the pulleys, of the outside…
