Building construction and superintendence, by F.E. Kidder ... (1896)
Kidder, Frank E. (Frank Eugene), 1859-1905 · New York, W.T. Comstock · leaf 65
aming of a brick and wooden building is in the mannerof supporting the joistr- over the outside door and window openings.In wooden buildings the joists are supported by the sill, girt or plate,but in brick buildings there is nothing corresponding to these. When 62 B UILDING CONS TR UC TION. the top… … Fig. 36. comas within 14 inches of the joists, as is usually the case with base-ment windows, the joists should either be framed into a header, asshown in Fig. 37, or a steel beam should be placed over the opening. WOOD FRAMING. 63 This is a point that must not be overlooked in laying out the…
