Kidder, Frank E. (Frank Eugene), 1859-1905 · New York, Comstock · leaf 502
Fig. 316. Segmental Tile Floor Arch. foot of span, and 13^^ inches wherever practicable. The rule issometimes given, that the rise of the soffit of the arch above thespring line should be from i-io to y^ of the span. As the riseincreases, the thrust decreases. The considerable thrust of these…
Building · Carpentry · Masonry
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
