Kidder, Frank E. (Frank Eugene), 1859-1905 · New York, Comstock · leaf 788
nd a single terra-cotta lintelresting on angle shelf and also hung on hook-bolt, and the wallfacing above resting on angle shelf fastened to steel bracket fromthe plate-girder. Fig. 605 shows metal supports formed by I-beam, angle andanchor. The terra-cotta lintel has a shelf bearing with… … Liiv-tel vitk skelf be&rin.rt wllK. pj\.c\\or claLm,|3ecl oei- to)? [L^n^eof be&JTV— Note a-rrarviJeirvcivC cf>it«.ff beauci for [3re\eivtttvg ir\jur^ IaTC by defLectlotv of bea.Ti\. Fig. 605. Steel Supports for Masonry.I-beam, Angle and Anchor.
Building · Carpentry · Masonry
