COLISEUM ROOFS. 197 … Fig. 233.—Center Hinge of Truss. The longitudinal struts between the trusses are lattice girders 2feet deep, having pairs of 3 x 3 x §-inch chord angles and single2.\ x 2\ x 5/ie-inch zigzag web angles. They are web connectedto the upper ends of the vertical members in the trusses, and have3 x…
