Building construction and superintendence, by F.E. Kidder ... (1896)
Kidder, Frank E. (Frank Eugene), 1859-1905 · New York, W.T. Comstock · leaf 291
can readily obtainih and ik. Problem 21, Fig. 296. Eight Panel French Truss, like Fig. 69,except that the tie from joint 1 to joint 6 is inclined, the stress dia-gram is drawn precisely as explained in Prob. 19. It should be noticed that inclining the tie, materially increases thestresses in all… … .Stress Diagram. Fig. 29 BUILDING CONSTRUCTION. 283 finding the point k by means of the dotted line, and working back-wards from 1 and g to find the point h. It is interesting to note thatwith vertical struts the stress is uniform throughout the rafter, andthat the stress in all of the web members…
