n& Schmitt, architects, is supported by six three-hinged plate-girderarches, that is, with a solid web instead of bracing. This is the onlyinstance of a solid web in large arches with which the writer isacquainted, and it would appear as though it might be advantage-ously employed in many… … Fig. 103. of these trusses are published in the Engineering Record of De-cember 26, 1896. Other examples of three-hinged arch trusses are given inChapters VI. 42. BRACED ARCHES WITHOUT HINGED JOINTS.—For spans of from 80 to 120 feet this type is often built withoutthe pin connections as in Fig.…
