hey are fastened with small finish nails. Thicknesses.—All parts of the window frame except the sill andyoke are commonly made of |-inch stuff. For large windows thepulley stiles should be \\ inches thick, and if no strip is inserted be-tween the outer sash and the casing, the latter should also be… … Fig. 96. SHEATHING, WINDOWS, ETC. 115 advantage. The parting strip, E, is usually made | of an inch thickfor i|-inch sash, and \ inch thick for \\ or 2^-inch sash. The yokeis made from | inch to if inches thick, according to the custom ofthe locality. A thickness of i^ inches is just as good as if…
