et that opens down.By this arrangement the lid ismade self-supporting when open,without the aid of elbow bracesor chains, and the pivot hingecan be made quite strong, while being at the same time concealed. 192. Drawers.—These occur in most of the fittings usually de-signed by the architect, and… … Fig. 318. B UILDING CONS TR UCTION. should be made so that there will be only sufficient contact with thedrawers to support and guide them. Fig. 318 shows the usual con-struction of the case with the top omitted. The bottom edge of thedrawer slides on the piece A, while the piece B guides it. The…
