441 showsthe more common type of such hinges, the position of the parts beingthat assumed when the blind is thrown open. Two sizes of platesare made, 2 and 2^-inch, the latter affording a more secure attach-ment. If there is a moulding on the casing, a wider hinge plate andlonger hook must be used… … Fig. 442.—Wrought Blind Hinge. New York Style. 4-inch throw may be used on brick buildings, with 4-inch reveal tothe windows. These hinges are very simple and inexpensive, andbeing made of steel will not break. Fig. 442 shows a style of wrought steel hinge much used in NewYork City, where blinds…
