ELEVATIONOF PIPI NO … Pig. 24. Plan and Sectional Elevation of Feeders in Storehouse. A and B, with especially large hoppers, which are driven by anelectric motor and which deliver the cotton to the conveying pipe,C, through montlrpieces, D. The fan, E, for drawing the cottonthrough the pipe, is placed in the opener…
