Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter G. (Walter Gilman), 1858-1908 · New York, J. Wiley & Sons · leaf 229
e and the inner circle of the house is 50 ft.The angle of the stalls is 9 degrees. The panel lengtli on the inner circle is 12 ft. 6 in. The clearheight from the top of rail to the roof girder at the outer walls is i8 ft. Two of the stalls are usedas passage-ways, with brick fire-walls on each… … Fig. 324.—General Plan.
Railroads -- Buildings and structures · Buildings
