Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter G. (Walter Gilman), 1858-1908 · New York, J. Wiley & Sons · leaf 230
Chief Engineer, B., C. R. & N. Ry., is a 5-stall segment of a brick roundhouse,with iron posts on the inner circle, and timber posts in the interior supporting a low flat roof, coveredwith roofing-felt and gravel. The house is 70 ft. wide, outside measurement, and the panel length onthe inner… … Fig. 329.~Cross section.
Railroads -- Buildings and structures · Buildings
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
