Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter G. (Walter Gilman), 1858-1908 · New York, J. Wiley & Sons · leaf 80
Fig. 114.—Side Elevation. … Fu;. 115.—Cross-section AND Fkoni Elevation. Fig. 116.—Ei.KVATioN ok Frame. 42 BUILDINGS AND STRUCTURES OF AMERICAN RAILROADS. X 4 in.; rafters, 3 in. X 4 in.; Iloor-joists, 3 in. X 6 in., spaced iS in.; windows, double sash, eachsash four lights, 10 X 12; door, 2 ft. 9 in. X 6 ft. 4 in.;…
Railroads -- Buildings and structures · Buildings
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
