Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter Gilman, 1858-1908 · New York Wiley · leaf 78
^^^ … Fig. 115.—Cross-section .\ND Front Ei.evatio.n. Fig. 116.—Ei,EV.\TioN of Frame. 42 BUILDINGS AND STRUCTURES OF AMERICAN RAILROADS. X 4 in.; rafters, 3 in. X 4 in.; floor-joists, 3 in. X 6 in., spaced 18 in.; windows, double sash, eachsash four lights, 10 X 12; door, 2 ft. 9 in. X 6 ft. 4 in.;…
