Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter G. (Walter Gilman), 1858-1908 · New York, J. Wiley & Sons · leaf 81
dry signal and road supplies. Steps inside the towerlead to the upper floor or the signal-room, in which the operator or signalman is stationed, sur-rounded by the necessary signaling and telegraphic apparatus. The general design of this tower isvery ornamental and attractive, while the details are… … V -1 =», ^V i \X- 11 \\ Fig. 117.—Second-fi.oor Plan. Fig. ii8.^Second-floor Fr,\m!ng Plan. Where an extensive and complicated switch system is connected with a block station, the spaceoffered by the building under discussion is too smalt for the accommodation of the switch levers, andanother…
Railroads -- Buildings and structures · Buildings
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
