Fig. 124.—Side Elevation. The principal timbers used are as follows : sills, 6 in. X 8 in.; floor-joists, 3 in. X 8 in.; ceiling-joists, 2 in. X 8 in.; interties, 4 in. X 6 in.; plates, 4 in. X 6 in.; corner-posts, 6 in. X 8 in.; studs,3 in. X 4 in.; angle-braces, 3 in. X 4 in.; rafters, 3 in. X 6…
