Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter Gilman, 1858-1908 · New York Wiley · leaf 179
hauled up and set on the platform.When an engine stops for coaling, the buckets are picked up by the crane, swung over the tender,and discharged. The height of the shed is 12 ft. from sill to plate, and the bents are spaced 6 ft. apart. The 142 BUILDINGS AND STRUCTURES OF AMERICAN RAILROADS.… … H-i I a-a i \ \ Fig. 267.—Front Elevation.
Building · Railroads
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
