Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter Gilman, 1858-1908 · New York Wiley · leaf 227
le and the inner circle of the house is 50 ft.The angle of the stalls is 9 degrees. The panel length on the inner circle is 12 ft. 6 in. The clearheight from the top of rail to the roof girder at the outer walls is 18 ft. Two of the stalls are usedas passage-ways, with brick fire-walls on each… … Fig. 324.—General Plan.
