Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)
Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 120
oosing the motion for rise andfall exactly the same, secure the same motion for the reversed as forthe forward movement of the cam. Cylindrical CamsDevelopment of Cylinder Cams. Suppose that the outline ofthe translation cam as developed in Fig. 91 be wrapped around acylinder whose circumference is… … Fig. 92. Development of Cylindrical Cam cylinder is rotated on its axis, the cycle of follower movement will berepeated as long as we choose to rotate the cylinder. Such a groovedcylinder is known as a cylindrical cam. Fig. 92 shows a cylindrical cam in two projections. Attentionis called to the…
Machinery
