Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter Gilman, 1858-1908 · New York Wiley · leaf 281
Fig. 418.—Front Elevation. Fig. 419.—End Elevation. n The outside of the building is sheathed with weather-boarding, and roofed with shingles. The prin-cipal materials used are, 6-in. X 6-in. posts; 2-in. X 4-in. studs; 2-in. X 4-in.purlins; 2-in. X 4-in. gable frame; 2-in. X 6-in. struts; 2-in. X…
Building · Railroads
