10 0 10 20 SO 40 60 Scale of Feet lo Figs. 3—8. 100 A, Chapel or Musi. room.—B, B, B, Linen rooms—C, Bed room —D, D, Assistants Bed rooms.—E, E, E, Girls dormitories.—F, Linen presses.—G, Girls Washingroom.—H, I. K, I, Superintendent* Apartments ; consisting of, H, Kitchen ; I, Bed room, K, Sitting… … FIG. 10—SECTION OF KITCHEN.(N, Fig. 3.)
