Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter Gilman, 1858-1908 · New York Wiley · leaf 327
Fig. 528.—Ground-plan. centres; floor, double, with building-paper between; frame, 3-in. X 6-in. studs; plates, 3 in. X 6 in.,double; rafters, 3 in. X 6 in., spaced 24 in. centres; ceiling-joists, 3 in. X 6 in.; struts and ties, \\ in.X 6 in.; i-in. roof-boards. Passetiger Depot, Boston, Hoosac…
Building · Railroads
