Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter Gilman, 1858-1908 · New York Wiley · leaf 54
Fic. 50.—Grou.nu-plan.doors, 3 ft. X 7 ft. … Fig. 51.—End Elevation. -Ground-plan. Fig. 52. lay-out to the design of the Chesapeake & Ohio Railway, just described ; but it is a much cheaperbuilding and less importance is given to the exterior. The design shows a one-story L-shapedframe building, 28 ft. X 16 ft., the wing being 16 ft. X 12…
