Building stone, lathing, plastering, and tiling, common brickwork, ornamental brickwork and terra cotta : lighting fixtures, use and design of lighting fixtures, architectural design (1909)
International Correspondence Schools · Scranton : International Textbook Co. · leaf 236
Fig. 21 they are made level they are almost sure to settle and sag alittle and crack the glass in the sash. In the plan of thewindow opening and sill, Fig. 21 (b), a shows the reveal ofthe brickwork; l>, the 2-inch offset for the box frame of thewindow; and c, the window sill. The section (c)… … -,& cw Fig. 22 under side, or soffit, of the arch at a, and the wood lintel at d.This wooden lintel is placed behind the brick arch, and mayalso be used as a support for the floor joists. The lintel mayhave a bearing of from 4 to 6 inches at each window jamb. 22 ORNAMENTAL BRICKWORK §41 28.…
Building · Building materials · Architectural design · Lighting, Architectural and decorative
