~ V7392 - i52) = I §137] EXAMPLES OF GENERATOR CALCULATION. 559 All other dimensions of the frame can be directly derivedfrom Fig. 353. … —45— . 353- — Dimensions of Field-Magnet Frame, 50 KW Double-MagnetType, Low-Speed Generator. C. CALCULATION OF MAGNETIC LEAKAGE. i. Permeance of Gap Spaces. — -~ 76 ~ 4375 = 439 Ratio of radial clearance to pitch : .8765 = .286; Product of field density and conductor velocity: 20,000 x 32 =…
