Bradbury, F. (Fred) · Halifax : F. King · leaf 275
AND FABRICS. would be equal to the denominator of the fractionalpart of one thread in inches, because if the warp threadslie straight the weft threads would touch each other. Further, it is interesting to note that the averageangle produced by the weft remains unchangedwhatever be its thickness,… … Fig. 9- weft is reduced to ^io ^^ ^^ inch. The diagram (Fig. 9)is constructed in the same way as Figure 8. Thesame letters in each diagram refer to correspondingparts and the subsequent reasoning is identical in eachcase, consequently it is not necessary to repeat herethe process of construction…
Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
