Cambria steel; a handbook of information relating to structural steel manufactured by the Cambria Steel Co. (1903)
Cambria Steel Co · Philadelphia : Press of MacCalla & company, inc. · leaf 324
nt a countersink, the blackened circle for a field rivet and the diagonalstroke to indicate a flattened head. The position of the cross, with respect to thecircle (inside, outside or both sides), indicates the location of the countersink andsimilarly the number and position of the diagonal strokes… … 306 CAMBRIA STEEL. SHEARING- VALUE OF RIVETS AND BEARING VALUE OF RIVETED PLATES. ALL DIMENSIONS IN INCHES. Shearing Value = Area of Rivet X Allowable Shearing Stress per Square Inch. Diameter ofRivet. Area in Square Inches. SingleShear at6000 lbs. Double Shear at 12 000 lbs. Bearing Value for…
Steel, Structural · Building, Iron and steel · Building
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
