Mechanics and heat; a text book for collleges and technical schools (1916)
Franklin, William S. (William Suddards), 1863-1930, Macnutt, Barry, 1878-1936, [from old catalog] joint author · New York, The Macmillan company; London, Macmillan & co., ltd. · leaf 212
is everywhere under longitudinal strain as shown in Fig. 90; andthe force action between contiguous parts of the beam is as shownin Fig. 91. These figures may be understood by comparing them … Fig. 90. with Figs. 85 and 86. To find the value of the stress and strainat each point in the bent beam proceed as follows: Consider the portion of the beam which lies between the radiiR and R, Fig. 88. This portion is shown to a larger scale inFig. 92. Let R be the radius of curvature of the…
