necessary toproduce the fabric, before the loops are interknit andcast off. Fig. 1 shows a portion of the cylinder and its needles ;Fig. 2, a portion of the dial and its needles. Fig. 3 isa perspective view of a part of the machine. Fig. 4 isa vertical section on the line 4—4 of Fig. 3. The yarn, a… … are mounted on a cam cylinder and the needles are firstdrawn down by the cam drawing the thread or yarndown over the dial needles, which are then advanced,at a point (Fig. 2) back of the open latches of the dialneedles, to the low point indicated at Fig. 1, just be-low the iipper edge of the…
